2023 Benelli TNT135  Featured

Stock #tnt135green
MSRP: $3,269 USD

655 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2023 Benelli TNT . I'm in the area and you can reach me at or by phone at .


  • Status:
    New
  • Vehicle:
    2023 Benelli TNT135
  • VIN:
    TNT135GREEN
  • Model Number:
    #TNT135
  • Color:
    Green
  • Stock Number:
    tnt135green
  • Location:
    Bobby J's Yamaha, Albuquerque, NM 87110
  • Warranty:
    Manufacturer's w/ Extended Available

BRAKES

  • Front Brake Diameter (in):
    8.7
  • Front Brake Diameter (mm):
    220
  • Front Brake Type:
    Disc
  • Rear Brake Diameter (in):
    7.5
  • Rear Brake Diameter (mm):
    190
  • Rear Brake Type:
    Disc

ENGINE

  • Bore (in):
    2.13
  • Bore (mm):
    54
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    9.8
  • Cooling:
    Oil
  • Cylinders:
    1
  • Displacement (cc):
    134.7
  • Displacement (ci):
    8.2
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    Single-Cylinder
  • Fuel Injector Size (mm):
    28
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Horsepower (bhp):
    11.3
  • Horsepower (kW):
    8.4
  • Horsepower RPM:
    8500
  • Starter:
    Electric
  • Stroke (in):
    2.31
  • Stroke (mm):
    58.8
  • Torque (Ft Lbs):
    7.4
  • Torque (Nm):
    10
  • Torque RPM:
    7000
  • Valve Configuration:
    SOHC
  • Valves Per Cylinder:
    4
  • Valves:
    4

EXTERIOR

  • Body Material:
    Plastic
  • Chain Guard:
    Yes
  • Foot Peg Location:
    Driver and Passenger
  • Fork Guards:
    Yes
  • Frame:
    Steel
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    LED

SEATS

  • Number Of Seats:
    2
  • Seat Height (in):
    30.7
  • Seat Height (mm):
    780
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Type:
    Two-Piece

STEERING

  • Steering Control:
    Handlebar

SUSPENSION

  • Front Suspension Size (in):
    1.6
  • Front Suspension Size (mm):
    41
  • Front Suspension Type:
    Inverted Fork
  • Front Travel (in):
    4.7
  • Front Travel (mm):
    120
  • Number Rear Shock Absorbers:
    1
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Material:
    Aluminum
  • Rear Suspension Size (in):
    2
  • Rear Suspension Size (mm):
    50
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5
  • Rear Travel (mm):
    126

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    116
  • Dry Weight (lbs):
    255.7
  • Engine Displacement to Weight (cc):
    0.53
  • Fuel Capacity (gal):
    1.9
  • Fuel Capacity (l):
    7.2
  • Ground Clearance (in):
    6.3
  • Ground Clearance (mm):
    160
  • GVWR (kgs):
    150
  • GVWR (lbs):
    330.7
  • Height (in):
    40.4
  • Height (mm):
    1025
  • Length (ft):
    5.74
  • Length (ft/ft):
    5
  • Length (ft/in):
    8.9
  • Length (in):
    68.9
  • Length (mm):
    1750
  • Wet Weight (kg):
    121
  • Wet Weight (lbs):
    266
  • Wheelbase (in):
    47.8
  • Wheelbase (mm):
    1215
  • Width (in):
    29.7
  • Width (mm):
    755

TRANSMISSION

  • Final Drive Ratio:
    2.65
  • Gear Ratio (1):
    2.83
  • Gear Ratio (2):
    1.82
  • Gear Ratio (3):
    1.33
  • Gear Ratio (4):
    1.1
  • Gear Ratio (5):
    0.91
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Chain
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    120/70 ZR12
  • Front Tire Aspect Ratio:
    70
  • Front Tire Width:
    120
  • Front Wheel Diameter:
    12
  • Front Wheel Width (in):
    3
  • Rear Tire (Full Spec):
    130/70 ZR12
  • Rear Tire Aspect Ratio:
    70
  • Rear Tire Width:
    130
  • Rear Wheel Diameter:
    12
  • Rear Wheel Width (in):
    3.5
  • Tube / Tubeless:
    Tubeless
  • Wheels Composition:
    Aluminum
